ZE07-CO UL listed Electrochemical CO Module

For co detection in residential and commercial areas

Applications :

* co detector/monitor/alarm
*air-quality monitor device *air ventilation system
*smart home *Parking lot CO detection

Product Advantages:

*UL listed sensor
*7 years lifespan
*Extremely low power consumption
*Excellent Linear output
*Provide UART/Analog Voltage output
*Excellent ability of Anti-interference
*Provide Temperature compensation

Product Description:

ZE07-CO is a general-purpose and miniaturization electrochemical carbon monoxide detection module. It utilizes electrochemical principle to detect CO in air which makes the module with high selectivity and stability. Built-in temperature sensor can do temperature compensation; and it has digital output and analog voltage output. It is a combination of mature electrochemical detection principle and sophisticated circuit design.

Technical Parameters:

Model No.	ZE07-CO
Target Gas	CO gas
Interference Gas	Alcohol and other gases
Output Data	DAC(0.4~2V standard voltage output corresponding to 0~full scale)
Output Data	UART Output (3V-TTL Electrical Level)
Working Voltage	5V~12V (No voltage reverse connect protection)
Warm up time	≤3minutes
Response time	≤60s
Resume time	≤60s
Detection Range	0~500ppm
Resolution	0.1ppm
Operating Temp.	-10°C~55°C
Operating Hum.	15%RH~90%RH(No condensation)
Storage temp.	-10°C~55°C
Working life	3-5 years (in air)
